Product
Motion Capture Gloves
High-precision hand motion capture device
LinkerBot Motion Capture Gloves are a high-precision hand motion capture device designed for intelligent robot control and remote manipulation. Using advanced motion capture technology with 15 magnetic encoders combined with a self-developed dynamic mapping algorithm, they achieve precise control of dexterous hands.
Motion Capture15 EncodersWirelessReal-Time
Features
Advantages & Characteristics
01
High-Precision Motion Capture
Uses 15 magnetic encoders to capture finger and hand joint bending angles and yaw angles in real time. Each finger has 3 high-precision encoders measuring root bending, yaw, and fingertip angles.
02
Real-Time Dynamic Mapping Calibration
Combines proprietary dynamic mapping calibration algorithm for precise hand data mapping, ensuring efficient and accurate dexterous hand reproduction. Supports real-time calibration adjustable to different hands or scenarios.
03
Wireless High-Speed Data Transmission
Indoor range up to 20 m, outdoor up to 40 m (unobstructed). Uses 2.4 GHz wireless communication with pairing support — one receiver board for up to 2 devices.
04
Long Battery Life
Built-in 2000 mAh rechargeable battery supporting 8+ hours of continuous operation. Charges via microUSB in under 2 hours.
05
Vibration Feedback
Built-in motor vibration feedback module provides tactile feedback during remote operation, improving accuracy and immersion.
06
Broad Compatibility
Works with multiple software environments, providing a C++ SDK and supporting 3D MAX, MAYA, Blender, and more for easy secondary development and integration.
Use Cases
Application Scenarios
Robot Teleoperation
Real-time hand motion capture for intuitive remote control of dexterous robotic hands.
Data Collection
Capture hand motion data for machine learning training datasets and manipulation research.
VR & Simulation
Precise hand tracking for virtual reality applications and robotic simulation environments.
Specifications
Product Details
| Sensor Thickness | 0.1 mm |
|---|---|
| Sensor Stretch Range | 0%–50% |
| Sensor Durability | 2.1 million cycles |
| Number of Sensors | 12 |
| Minimum Resolution | ≤0.1° |
| Single Glove Weight | < 45 g |
| Interface | Type-C |
| Wireless Transmission | 2.4 GHz |
| Transmission Distance | 15 m |
| Transmission Frame Rate | 120 Hz |
| Data Latency | < 10 ms |
| Anti-Interference | Not affected by magnetic fields |
| Charging Time | < 2 hours |
| Battery Life | 10 hours |
| Material | 5A antibacterial fabric |
| Cleaning Method | Gentle hand wash |
| Operating Temperature | 5°C–60°C |
| Spatial Positioning | Optical tracker or base station binding |
| System Compatibility | Windows 7 and above |
